JONARD EDP-91466 Punchdown Tool Kit
The JONARD EDP-91466 Punchdown Tool Kit is a professional wire termination tool designed for cleanly seating and trimming wires in 66-style cross-connect blocks. It includes the EPD-914 punchdown tool and an EPB-66 punchdown blade, making it suitable for telecom and data-communications installation and maintenance.
The tool features high/low impact settings, with 40 lb (178 N) at high impact and 30 lb (133 N) at low impact, and is designed to terminate 22–28 AWG solid or stranded wire. It also includes an integrated combination hook/spudger and enlarged blade-storage compartment.
Key Features
Designed for 66-style cross-connect blocks
Includes EPB-66 66-style punchdown blade
High/Low impact settings
Suitable for 22–28 AWG (0.08–0.34 mm²) solid or stranded wire
Integrated combination hook/spudger
Yellow-and-blue color-coded body
Enlarged blade-storage compartment
Tested for up to 100, 000 cycles at high-impact setting
Compatible with EPB-series replacement blades
Lifetime warranty from JONARD Tools according to the manufacturer
Ideal for telecom and data-communications installation work
Specifications
Specification Details
Stripping Range Not applicable – punchdown/termination tool
Fiber Type Not applicable
Stripping Stage Not applicable
Tool Type Manual Punchdown / Wire Termination Tool
Blade Material Hardened alloy steel with nickel plating
Handle Type Ergonomic molded tool body/hand grip
Length 7 in (17.78 cm)
Weight 0.31 lb (140.74 g)
Body Material Durable molded tool body; manufacturer does not specify the exact polymer grade
Blade Type 66-style punchdown blade
Block Type 66
Wire Size 22–28 AWG (0.08–0.34 mm²)
Impact Settings High: 40 lb / 178 N; Low: 30 lb / 133 N
Dimensions 7 x 1.5 x 1 in (17.78 x 3.81 x 2.54 cm)
Color Yellow and Blue
Supplier / Authorized Dealer Miracle Tools and Tackle LLP
The blade material specification is based on JONARD's official EPB-66 blade information, which states that the blade is made from hardened alloy steel with nickel plating. The EDP-91466 dimensions and weight are specified by JONARD as 7 x 1.5 x 1 in and 0.31 lb (140.74 g).
What's Included
1 × EPD-914 Punchdown Tool
1 × EPB-66 Punchdown Blade (66 blade, with/without cutter configuration)
Applications
The JONARD EDP-91466 is suitable for:
Telecom installation and maintenance
Data communication wiring
66-style cross-connect blocks
Structured cabling work
Network installation
Communication equipment servicing
Professional wire termination and trimming
Frequently Asked Questions
1. What is the JONARD EDP-91466 used for?
The EDP-91466 is used to terminate and trim wires in 66-style cross-connect blocks. It is designed primarily for telecom and data-communications installers.
2. What blade comes with the EDP-91466?
The kit includes the EPB-66 66-style punchdown blade.
3. What wire sizes can this tool terminate?
The EDP-91466 can terminate 22–28 AWG (0.08–0.34 mm²) solid or stranded wire.
4. Does the EDP-91466 have adjustable impact settings?
Yes. It has High and Low impact settings. High impact is rated at 40 lb (178 N), while low impact is rated at 30 lb (133 N).
5. Is the EDP-91466 a fiber-optic stripping tool?
No. The EDP-91466 is a punchdown and wire termination tool, so fiber type, stripping range and stripping stage are not applicable.
6. What material is the punchdown blade made from?
The EPB-66 blade is made from hardened alloy steel with nickel plating, providing durability for repeated professional use.
7. What are the dimensions of the EDP-91466?
JONARD specifies the dimensions as 7 x 1.5 x 1 inches (17.78 x 3.81 x 2.54 cm).
8. How much does the EDP-91466 weigh?
The tool weighs approximately 0.31 lb (140.74 g).
9. Does the tool include a hook or spudger?
Yes. A combination hook/spudger is stored in the tool chassis, providing an additional function for wire installation and servicing.
10. Is the EDP-91466 suitable for professional use?
Yes. JONARD designed the tool for telecom and data-communications professionals and reports testing of up to 100, 000 cycles at the high-impact setting.
11. Can the blade be replaced?
Yes. The EPB-66 is available as a replacement punchdown blade and is also compatible with other industry-standard twist-and-lock style punchdown tools.
12. Who is the supplier for this product?
Miracle Tools and Tackle LLP is the supplier/authorized dealer specified for this product listing.
Product Summary
The JONARD EDP-91466 Punchdown Tool Kit is a compact and durable solution for professional 66-style wire termination. With its 66 punchdown blade, adjustable impact settings, integrated hook/spudger and ergonomic design, it is well suited for telecom, networking and data-communication applications.
Supplier: Miracle Tools and Tackle LLP
